Large aperture and high depth of field achieve clear imaging with full field of view and no distortion

The measuring workpiece can be placed arbitrarily without positioning the fixture or focus adjustment.

One-Click Measurement

Accurate measurement, one click trigger.

Large aperture and high depth of field achieve clear imaging with full field of view and no distortion.

The measuring workpiece can be placed arbitrarily without positioning the fixture or focus adjustment.

Send Email

Chat Now

Share With:

Introduction

• Accurate measurement, one click trigger.

• Large aperture and high depth of field achieve clear imaging with full field of view and no distortion.

• The measuring workpiece can be placed arbitrarily without positioning the fixture or focus adjustment.

• It can realize the measurement of multiple positions of the workpiece, increase the measurement size, and measure quickly.

• Multiple workpieces can be measured simultaneously or a single workpiece can be measured as a whole.

• The measurement results can be automatically saved to the computer, and can be output in WORD, EXCEL, CAD and other formats

Features

It can realize the measurement of multiple positions of the workpiece, increase the measurement size, and measure quickly.

Multiple workpieces can be measured simultaneously or a single workpiece can be measured as a whole.

The measurement results can be automatically saved to the computer, and can be output in WORD, EXCEL, CAD and other formats

Technical Specification

Model	VE-60C	VE-80C	VE-100C
Field （mm）	47*35	63*46	82*55
Z Travel（mm）	30	30	50
Accuracy （μm）	E=（2.5+L/50）	E=（2.5+L/50）	E=（2.5+L/50）
Dimension（mm）	230266650	350×550×750	350×550×750
Weight（KG）	40	50	50
